Polyimide heater

Location:Home > Products > Polyimide heater

3M Adhesive Flexible 24V Kapton Heater/PI Electric Polyimide Heating Film

sort:XD-F-1
This product has been viewed
Sort:XD-F-1
Welcome to call us
alirubber.com@163.com
Product Details

Technical data:

1. Insulation:  UDC500V>=200M ohm

2. Dielectrical strength: UAC>=2000V

3. Opeartion temperature:  <=232C

4. Wattage density:  <=1.1W/cm2 or <=6.5W/cm2(with thermostat)

5. Thickness:  <=0.2mm Can bent at any angle

6. Weight:  <=278g/m2



Design instruction:

1. Drawing for maximum installation size of the heater

2. Relevant electric parameters: as wattage, voltage, resistance, current and tolerance

3. Direction,  length and location of the lead wire


Basic information:

1. Interior FEP binding stands 200°C.

2. Apply in vacuum environment.

3. Stand against most of chemical material such as acid, impregnant, alkali (except NaOH).

4. The size can be very small.

5. Thin and small curly semidiameter.

6. Temperature Range: -50°C~200°C, the max temperature is 150°C for the heater with paster.

7. Material: Kapton/FEP, polyimide membrane

8. Resistance Precision: ±10%ak±0.5Ω(taking max)

9. Medium Strength: 1000VRMS

10. Minimum Curve Semidiameter: (0.8mm)



Some features are as follow.



NO.

Description

Parameter

1.

Certification

CE

2.

Voltage range

1.5v~400v

3.

Power density range

0.07w/cm2~2.5w/cm2(0.19w/inch2~16.13w/inch2)

4.

Using temperature range

-60~200°C(-140~392°F)

5.

Width range

10mm~500mm(0.39"~19.68")

6.

Length range

10mm~1800mm(0.39"~70.86")

7.

Thickness range

Standard:0.126~0.266mm(0.005"~0.01")

8.

Plug

Chinese,British, American, European and so on

9.

Quality guarantee

1 year

10.

Life

more than 4 years(normal useful)

11.

MOQ

1 piece

OEM and ODM is welcome,can print your logo



Why Kapton

  • Heating for very small sizes
  • Very thin
  • High dielectric strength
  • Flexible circuit design
  • Superior tensile strength and tear resistance
  • Resistant to radiation and most solvents
  • Better choice far high watt density heaters (those over 5 watts/in2). Also used for watt densities of 5 or less.
  • Excellent choice for heaters that require multi-zoned wattages or heaters that have many holes and/or cutouts.
  • May provide an economic advantage for high volume applications.



Applications:

Alibrother supply polyimide heaters for many different applications such as industrial catering,

battery warming, environmental control or electronics (particularly telecommunications),

laboratory equipment and anti-condensation. The uses for polyimide heaters are infinite as

they can suit any application requiring surface heating up to 200°C. Their suitability for

arduous conditions has been proven in applications from polar expedition to space exploration.

We are the final frontier in polyimide heaters!
